GRAPH3D: Stata module to draw colored, scalable, rotatable 3D plots by Robin Jessen and Davud Rostam-Afschar

graph3d

# graph3d for Stata

This page illustrates the use of graph3d.ado for Stata. See Stata. To download the graph3d package including the ado file type

. ssc install graph3d in Stata or click

Before running any of the examples, set up the exemplary dataset by running

. clear
. set obs 630
. gen x = int((_n - mod(_n-1,30) -1 ) /30 )
. gen z = mod(_n-1,30)
. gen y = normalden(x,10,3)*normalden(z,15,5)*10000
. gen w = x*z

### Example 1: Default 3D-Plot

. graph3d x y z

### Example 2: Default 3D-Plot rotated by 75 degree about the width-axis

. graph3d x y z, xang(75)

### Example 3: Wireframe default 3D-Plot

. graph3d x y z, wire

### Example 4: Two-colored 3D-Plot

. graph3d x y z, colorscheme(cr)
[Try also . graph3d x y z x, colorscheme(cr)]
[and . graph3d x y z w, colorscheme(cr)]

### Example 5: Two-colored 3D-Plot with changing markers

. graph3d x y z, colorscheme(cr) mark

### Example 6: Equidistantly two-colored 3D-Plot with changing markers

. graph3d x y z, colorscheme(cr) mark equi

### Example 7: Five-colored 3D-Plot with changing markers

. graph3d x y z, colorscheme(bcgyr) mark

### Example 8: Grey scale 3D-Plot

. graph3d x y z, colorscheme(fade)

### Example 9: Snowball 3D-Plot

. graph3d x y z, markeroptions(mfcolor(white) mlcolor(black) msize(3))

### Example 10: Default 3D-Plot with outer grid-cuboid

. graph3d x y z, cuboid format("%03.0f")

### Example 11: Default 3D-Plot with outer and inner grid-cuboids

. graph3d x y z, cuboid innergrid format("%03.0f") blv

### Example 12: Perspective 3D-Plot

. graph3d x y z, ycam(-4) zcam(-18) cuboid innergrid blv perspective colorscheme(bcgyr)

### Example 13: Four-colored 2D-Plot

. graph3d x y z, xang(0) yang(0) zang(0) colorscheme(bcgyr)

### Example 15: graph3d for margins plot

download Stata code here

### Example 16: Happy Valentine's Day

download Stata code here

### Example 17: Growing 3D spiral

download Stata code here

### Example 18: Spining 3D sphere in 16:9

download Stata code here

### Example 19: Spining 3D sphere in 1:1

download Stata code here

### Example 20: Rotating banana function

download Stata code here

### Authors

Robin Jessen
Freie Universität Berlin
robin.jessen@fu-berlin.de

Davud Rostam-Afschar
Universität Hohenheim
davud.rostam-afschar@uni-hohenheim.de
